65kVA silent diesel genset adopts SDEC 4ZT4.1-G21 inline 4-cylinder turbo engine, 50Hz 3-phase 400V, PF0.8, ISO8528 compliant. Fuel-efficient and stable operation with IP23 brushless alternator. Compact soundproof canopy with shock absorption, rain & dust resistant for shops, residential quarters and small construction sites.
Prime 50kVA, standby 55kVA silent genset powered by SDEC 4ZT3.5-G21 inline 4-cylinder engine, 50Hz 3P 400V, PF0.8, ISO8528 compliant. Turbo design with low fuel consumption, matched with IP23 brushless alternator. Compact soundproof canopy with shock absorption, rain & dust proof, ideal for shops, residential areas and small construction sites.
The CDS220KVA is Jiuan Generator's 220KVA SDEC diesel generator built for demanding medium-scale industrial and commercial power requirements. Powered by the authentic SDEC SC8D280D2 inline six-cylinder engine with replaceable wet cylinder liner design, this 220KVA standby power supply delivers 160KW/200KVA prime and 176KW/220KVA standby output to ISO8528 PRP and ESP standards. A fully sealed soundproof canopy with 550L integrated fuel tank, H-class brushless alternator, and Deepsea DSE7320 controller make the CDS220KVA a dependable 200KVA prime power generator for factories, hospitals, commercial complexes, and off-grid mining operations.
The CDS165KVA is Jiuan Generator's 165KVA SDEC diesel generator engineered for the 120–132KW light industrial and commercial backup power range — a capacity bracket where township hospitals, small processing plants, and downtown commercial centers need dependable power without the capital overhead of oversized 200KVA units. Driven by the SDEC SC7H205D2 four-valve inline six-cylinder engine, this 165KVA standby power supply delivers 120KW/150KVA prime and 132KW/165KVA standby output to ISO8528 PRP and ESP standards, housed in a ≤72dB(A) silent enclosure with a 420L base fuel tank for extended independent operation.
The CDP150KVA is Jiuan Generator's 150KVA Perkins diesel generator built for prime and standby power at remote project sites, mining operations, and commercial facilities where parts availability and on-site serviceability matter as much as rated output. Powered by the Perkins 1106A-70TG1 engine with direct mechanical fuel injection, this 150KVA standby power supply delivers 108KW/135KVA prime and 120KW/150KVA standby output to ISO8528 PRP and ESP standards. At ≤68dB(A) at 7 meters, it is among the quietest units in the 100–150KVA class — suited for urban commercial installations alongside remote site deployments.
This unit has 250KVA prime power and 275KVA standby power, equipped with original Perkins 1206A-E70TTAG3 engine with stable operation and low fuel consumption. Designed with super silent canopy for low noise. It adopts brushless alternator to ensure steady voltage output, and the intelligent control system provides multiple safety protections. Durable and easy to maintain, it is applicable for residential areas, hospitals, shopping malls and office buildings as prime or emergency standby power supply.
The CDP275KVA is Jiuan Generator's 275KVA Perkins diesel generator built for continuous prime power and mission-critical standby applications in data centers, large commercial facilities, manufacturing lines, and mining processing plants. Powered by the Perkins 1206A-E70TTAG3 with dual sequential turbochargers and an air-to-air aftercooler, this 275KVA standby power supply delivers 200KW/250KVA prime and 220KW/275KVA standby output to ISO8528 PRP and ESP standards. EU Stage II and EPA Tier 2 compliant. The 400L integrated base fuel tank supports 7–9 continuous hours at full prime load.
The CDP275KVA is Jiuan Generator's 275KVA Perkins diesel generator engineered for construction project prime power and infrastructure standby applications. Powered by the Perkins 1206A-E70TTAG3 with an electronic governor holding frequency within ±0.5% under step-load changes, this unit handles the variable inductive loads typical of construction sites — tower cranes, concrete batching equipment, compressors, and welding sets — without the VFD trips and motor thermal faults caused by mechanical governor frequency excursions. ISO8528 PRP rated at 200KW/250KVA for continuous prime use; ESP rated at 220KW/275KVA for standby backup.
The CDP200KVA is Jiuan Generator's 200KVA Perkins diesel generator engineered for commercial prime power and standby applications — hotels, office buildings, retail centers, and mid-sized industrial facilities. Powered by the Perkins 1106A-70TAG3 with air-to-air aftercooled turbocharged induction, the unit delivers 144KW ISO8528 PRP prime power for unlimited continuous operation and 160KW ESP standby for emergency backup. EU Stage II emission certified. Silent canopy option rated ≤75dB(A) at 7m; DSE6120 AMF auto-start with ATS transfer in under 10 seconds. 400L fuel tank supports 8–9 hours of autonomous operation.
The CDP50KVA is Jiuan Generator's 50KVA Perkins diesel generator for small business, rural community, and remote off-grid applications. Powered by the Perkins 1103A-33TG1 — a three-cylinder, 3.3L turbocharged engine with mechanical governor and 17.25:1 compression ratio — the unit delivers 36KW ISO8528 PRP prime power and 40KW ESP standby in a compact 2250×1000mm footprint weighing 1200kg. EPA Tier 2 and EU Stage II dual-certified. Cold start rated to -20°C; silent canopy ≤75dB(A) at 7m; integrated tank for 8–10 hours autonomous operation.
The CDP250KW is Jiuan Generator's 250KW Perkins diesel generator for mining surface infrastructure, bulk mineral processing, and large industrial prime power. Powered by the Perkins 1706A-E93TAG2 — a six-cylinder, 9.29L engine with electronic high-pressure common-rail fuel injection and ECM electronic governor — the unit delivers 250KW ISO8528 PRP prime power and 275KW ESP standby. Fuel consumption: 52.3 L/h at 100% prime load. 500L integrated tank for 9+ hours full-load autonomy. EU Stage II / EPA Tier 2 certified; silent canopy ≤75dB(A) at 7m; 18-month or 2,000-hour warranty.
The CDP357KVA is Jiuan Generator's 357KVA Perkins diesel generator for critical facility emergency standby power. Powered by the Perkins 1706A-E93TAG1 — a six-cylinder, 9.3L engine with common-rail electronic injection — the unit delivers 285KW/357KVA ISO8528 ESP standby and 245KW/306KVA prime, with a 16% standby headroom above prime for motor inrush absorption at ATS transfer. Fuel consumption: 58.5 L/h at 100% standby load; 500L tank for 8+ hours autonomy. EU Stage II / EPA Tier 2; silent canopy ≤75dB(A) at 7m; 18-month warranty.
